PRODUCT DESCRIPTION
Most popular and widely applied of all glass insulations. A color coded fiberglass braid saturated
with a high performance resin is used for insulation of the single conductors and jacket.
PERFORMANCE FEATURES
- Designed for continuous use at temperatures to 900°F (482°C), intermittent use in 1000°F(537°).
- Good moisture and chemical resistance; fair abrasion resistance.
APLICATIONS
- Heat treating
- Glass and ceramic kilns
- Foundries
- Extensive applications in aluminum processing
- Power generating plants
- Petroleum plants
- Field heat treating
|
CONDUCTOR SIZE |
INSULATION THICKNESS |
JACKET THICKNESS |
OUTER DIAMETER |
NET WEIGHT |
|---|---|---|---|---|
|
16 |
.007 |
.010 |
.100 x .150 |
20 |
|
16 (7) |
.007 |
.010 |
.094 X .168 |
22 |
|
18 |
.007 |
.010 |
.070 X .124 |
13 |
|
20 |
.006 |
.006 |
.056 X .100 |
8 |
|
20 (7) |
.006 |
.006 |
.060 X .108 |
9 |
|
24 |
.006 |
.006 |
.040 X .068 |
4 |
|
24 (7) |
.006 |
.006 |
.048 X .084 |
4 |
* Dimensions and weights shown are nominal, subject to standard industry tolerances.
*The products listed above represent the most popular constructions. Other constructions can be manufactured for your
application and requirements. Consult our sales office for additional information.
The above listed order code may be ordered in all thermocouple types
