Thermocouple 2 Wire FEP 400ºF 205ºC
º
2 Wire Temperature Sensor (2 Wire TC) Accurately measures temperature using only two wires, simplifying installation. It is Ideal for applications where space and simplicity are paramount. Perfect for temperature monitoring and control across various industries.
EXTRUDED FEP (FLUORINATED ETHYLENE PROPYLENE) PRODUCT DESCRIPTION
- Color coded FEP (Fluorinated Ethylene Propylene) is extruded over each single conductor.
- The single insulated conductors are laid parallel and insulated with an extruded jacket FEP (Fluorinated Ethylene Propylene).
Performance Features
Applications
Thermocouple Wire layout
Table Data
|
CONDUCTOR SIZE |
INSULATION THICKNESS |
JACKET THICKNESS |
OUTER DIAMETER |
NET WEIGHT |
|---|---|---|---|---|
|
16 |
.008 |
.010 |
.087 x .154 |
22 |
|
16 (7) |
.008 |
.010 |
.087 x .168 |
24 |
|
18 |
.008 |
.010 |
.076 x .132 |
15 |
|
20 |
.008 |
.010 |
.068 x .116 |
11 |
|
20 (7) |
.008 |
.010 |
.075 x .124 |
12 |
|
24 |
.008 |
.010 |
.056 x .092 |
6 |
|
24 (7) |
.008 |
.010 |
.060 x .100 |
7 |
|
30 |
.008 |
.010 |
.046 x .072 |
3 |
